The OppiLab spray booth is designed for school environments, enabling the safe use of spray paints and fixatives. The airflow rate is dimensioned specifically for educational use.
- Steel frame and high-quality components ensure a long service life
- Replaceable filter fabric and rotating painting stand included as standard
- Lockable base cabinet provides storage space for paints and other supplies
Product information:
- Standard width [mm]: 1000
- Other widths [mm]: 800, 1200
- Worktop depth [mm]: 540
- Overall depth [mm]: 620
- Overall height [mm]: 1850
- Clear working opening height [mm]: 870
- Worktop material: Acid-resistant stainless steel
- Side and rear wall material: Powder-coated steel
- Base cabinet and lock: Powder-coated steel cabinet with Abloy Classic lock
- Ventilation: Ø 200 mm connection collar on top for connection to a separate exhaust fan
- Lighting: Available with LED or ATEX lighting; light switch not included
- Airflow rate: Extract airflow 150 l/s, resulting in a pressure drop of approx. 150 Pa
